Hosts

• Compatible with PS/2 and Unix computers.
• Use with NTI Multi-Platform KVM Switches to control multiple PC, SUN and MAC computers.

Monitor

• Forward-folding 15" Active Matrix LCD flat panel monitor.
• 1024x768 video resolution.
• Supports Composite Sync and separate TTL level Sync. Does not support Sync on Green. Not compatible with all Sun Microsystems.
• Frequency:
  • Horzontal: 30 to 64 KHz
  • Vertical: 50 to 75 Hz
• Viewing angle: Horizontal: 115°, Vertical: 115°
• OSD controls for brightness, contrast, phase, pitch, Horz- and Vert-center alignment, zoom and color adjustment.
• 250 nits brightness and 350:1 contrast ratio typical.
• Supports DDC1 and DDC2B protocols.

Devices

• Two male 6 pin miniDIN (PS/2) connector.
• "Gold Crosspoint" keyboard contacts ensure high reliability.
• 105-key keyboard.
• Two button touchpad mouse.

Cables

• 6-foot 15 HD VGA male to male cable included.
• 6-foot 6-pin miniDIN keyboard/mouse cable included.
• 6-foot DC power supply cable included.

Power

• 110 or 220 VAC at 50 or 60 Hz via AC Adapter.
• Power consumption: 25W
• Maximum Inrush Current: 17A

MTBF

• 49,998 hrs

Environmental

• Operating temperature: 32°F to 104°F (0°C to 40°C).
• Storage temperature: -4°F to 140°F (-20°C to 60°C).
• Operating and Storage Relative Humidity: 5 to 95% non-condensing RH.

Dimensions

• WxDxH (in.): 19x20.1x1.75.
• Drawer is adjustable to various rack depths from 20.1" to 31.5".
