HDMI/DVI Extender via CAT5/5e/6: Extend up to 200 feet

Extend an HDMI or DVI Plasma/LCD display monitor up to 200 feet away from the source.

Also known as: HDMI extender, Media center extender, cat6 HDMI monitor extender,
remote digital HDMI monitor, HDMI transmitter/receiver, high defintion extender, extend video.

Additional Product Information

Data Sheet (PDF)

Customer Testimonial

DVI/HDMI Balun - Extend signal up to 200 feet

XTENDEX® ST-C5HDMI-200 (Remote and Local Unit)

Price Each:
$190

Features & Applications
The XTENDEX® HDMI/DVI Extender transmits digital video and audio signals up to 200 feet using two CAT5/5e/6 cables. Each video extender consists of a local unit that connects to an HDMI/DVI source and a remote unit that connects to an HDMI/DVI display. Ideal solution for digital signage applications. Transmits an HDMI signal over two CAT5/5e/6 cables.	Supports HDTV resolutions to 1080i and computer resolutions to 1920x1200. Compliant with HDMI 1.3 and HDCP 1.3 standards. Compliant with DDWG DVI standard. Supports the DDC2B protocol. Only one power supply is necessary to power both the local and remote units.

Specifications

Local Unit

One female HDMI-A port for source connection.
One female RJ45 port for sending high definition video/audio signals.
One female RJ45 port for sending DDC signal.

Remote Unit

One female HDMI-A port for HDTV or computer display.
One female RJ45 port for receiving high definition video/audio signals.
One female RJ45 port for receiving DDC signal.
Signal type: HDMI 1.3, HDCP 1.3 compliant.
Supports HDTV resolutions to 1080i and computer resolutions to 1920x1200.
Refer to the resolution chart below for resolutions at different lengths.
Supports audio through HDMI compatible TVs or audio receivers.

Power

Local unit: powered from remote unit through CAT5/5e/6 cable.
Remote unit: 110 or 220 VAC at 50 or 60 Hz via AC adapter.
Power consumption:
- Local Unit: Powered from remote unit.
- Remote Unit: 5W

Cables

Use HDMI-xx-MM cable to connect an HDMI source or display.
Use DVI-HDMI-xx-MM cable to connect a DVI source or display.
Use CAT5/5e/6 UTP straight through cable for TIA/EIA-568B wiring terminated with standard RJ45 connectors (not included).

Environmental

Operating temperature: 23°F to 130°F (-5°C to 55°C).
Storage temperature: -20°F to 140°F (-30°C to 60°C).
Operating and Storage Relative Humidity: 5 to 90% non-condensing RH.

Dimensions

WxDxH (in): 1.8x3.3x0.9

Regulatory Approvals

CE, FCC, RoHS

Warranty

Two years.

Connect a DVI PC to a DVI-D display up to 200 feet away

Connect an HDMI source device to an HDMI display up to 200 feet away

Distances and Resolutions for CAT5/CAT5e and CAT6 Cables
Cable	Distance (feet)	Maximum Standard Resolution	Maximum High Definition Resolution
CAT5 (UTP)	200	1024x768 at 60Hz	480i/p at 60Hz
	150	1280x1024 at 60Hz	720i/p at 60Hz
	100	1920x1200 at 60Hz	1080i at 60Hz
CAT5e (UTP)	250	800x600 at 60Hz	480i/p at 60Hz
	200	1024x768 at 60Hz	720i/p at 60Hz
	150	1280x1024 at 60Hz	1080i at 60Hz
	100	1920x1200 at 60Hz	1080i at 60Hz
CAT6 (UTP)	300	800x600 at 60Hz	480i/p at 60Hz
	250	1024x768 at 60Hz	720i/p at 60Hz
	200	1920x1200 at 60Hz	1080i at 60Hz
