Environment Monitoring IP Surveillance Camera

Wireless Day Night Network Monitor
Snapshot Control View MPEG-4 RJ45, how to

Environment Monitoring System IP Surveillance Cameras

Alert & Communication Accessories compatible with ENVIROMUX-2D, ENVIROMUX-5D and
ENVIROMUX-16D

IP Surveillance Cameras

Wired IP Surveillance Camera

ENVIROMUX-IPCAM IP Surveillance Cameras
ENVIROMUX-IPCAM
  • View the camera from the ENVIROMUX web interface, camera web interface, included software, or with a compatible cell phone.
    • Control the camera using the camera web interface accessible from the ENVIROMUX web interface.
  • With the ENVIROMUX-2D/5D/16D, a triggered snapshot can be forwarded in alert e-mails or stored locally on a connected flash drive.
    • A snapshot can be triggered by any programmed event (motion detection, door open/close, glass break, smoke, liquid detection, etc.)
  • Image sensor: 1/4" progressive scan CMOS sensor
  • Video Streaming: simultaneous Motion JPEG and MPEG-4
  • Frame rate: 30fps at 640x480 (VGA) resolution.
  • Lens: F2.0, 4.0 mm (0.16 in)
  • RJ45 connector.
  • Compatible with ENVIROMUX-2D/5D/16D.
  • Regulatory approvals: CE, FCC, RoHS
NTI Part # Price Quote Buy
ENVIROMUX-IPCAM $160.00

High-Definition Wireless/Wired IP Camera

ENVIROMUX-IPCAM-WH IP Surveillance Cameras
ENVIROMUX-IPCAM-WH
  • View the camera from the ENVIROMUX web interface, camera web interface, included software, or with a compatible cell phone.
    • Control the camera using the camera web interface accessible from the ENVIROMUX web interface.
  • With the ENVIROMUX-2D/5D/16D, a triggered snapshot can be forwarded in alert e-mails or stored locally on a connected flash drive.
    • A snapshot can be triggered by any programmed event (motion detection, door open/close, glass break, smoke, liquid detection, etc.)
  • Two-way Audio with built-in microphone and stereo audio output for external speaker.
  • 1.3 megapixel progressive scan CMOS sensor with 10x digital zoom.
  • Video streaming: simultaneous H.264, MJPEG, and 3GPP (dual streaming).
  • Frame rate: 30 fps at 1280x1024 (SXGA), 1280x720 (HD 720), 640x480 (VGA), 320x240 (QVGA).
  • Lens: F1.8, 4.3 mm (0.17 in).
  • Supports wireless 802.11 b/g/n with speeds up to 150Mbps.
  • Power: 12VDC.
  • 10/100 Mbps Ethernet port for wired connections.
  • Micro SD/SDHC memory card slot.
  • Requires Windows 7, Vista, or XP for initial installation.
  • Operating temperature: 32 to 104°F (0 to 40°C).
  • Operating humidity: 10 to 90% non-condensing RH.
  • Dimensions WxDxH: 2.1x1.4x2.9 in (54x35x76 mm).
  • Compatible with ENVIROMUX-2D/5D/16D.
    • ENVIROMUX-2D: only compatible with Rev C units (features two power inputs).
  • Regulatory approvals: CE, FCC, RoHS, C-Tick

NTI Part # Price Quote Buy
ENVIROMUX-IPCAM-WH $260.00

Wireless/Wired Day/Night IP Camera

Wireless Day/Night IP Camera
ENVIROMUX-IPCAM-WN
  • View the camera from the ENVIROMUX web interface, camera web interface, included software, or with a compatible cell phone.
    • Control the camera using the camera web interface accessible from the ENVIROMUX web interface.
  • With the ENVIROMUX-2D/5D/16D, a triggered snapshot can be forwarded in alert e-mails or stored locally on a connected flash drive.
    • A snapshot can be triggered by any programmed event (motion detection, door open/close, glass break, smoke, liquid detection, etc.)
  • Two-way Audio with built-in microphone and audio speaker.
  • IR-LED for night vision up to 15 ft (4.6 m) and provides minimum 1.0 Lux for low light environments.
  • 1/5" CMOS sensor with 4x digital zoom.
  • Video streaming: H.264, MJPEG.
  • Frame rate: 30 fps at 640x480, 320x240, and 160x120.
  • Lens: 3.15mm (0.12 in).
  • Supports wireless 802.11n/g.
  • UDP/TCP/HTTP/HTTPS protocols selectable.
  • WEP/WPA/WPA2-PSK wireless security available.
  • Power: 5VDC.
  • 10/100 Mbps Ethernet port for wired connections.
  • Requires Windows XP, Vista, 7, or 8 for operation.
  • Operating temperature: 32 to 104°F (0 to 40°C).
  • Operating humidity: 20 to 80% non-condensing RH.
  • Dimensions WxDxH:
    • Including bracket and stand: 2.60x2.56x4.96 in (66x65x126 mm).
    • Camera only: 1.06x2.36x3.78 in (27x60x96 mm).
  • Compatible with ENVIROMUX-2D/5D/16D.
    • ENVIROMUX-2D: only compatible with Rev C units (features two power inputs).
  • Regulatory approvals: CE, FCC, RoHS, C-Tick.
Downloads & References

NTI Part # Price Quote Buy
ENVIROMUX-IPCAM-WN $180.00

Wired Day/Night PTZ IP Camera with Power over Ethernet (PoE)

Wired Day/Night PTZ IP Camera with Power over Ethernet (PoE)
ENVIROMUX-IPCAM-NPOE
  • View the camera from the ENVIROMUX web interface, camera web interface, included software, or with a compatible cell phone.
    • Control the camera using the camera web interface accessible from the ENVIROMUX web interface.
  • With the ENVIROMUX-2D/5D/16D, a triggered snapshot can be forwarded in alert e-mails or stored locally on a connected flash drive.
    • A snapshot can be triggered by any programmed event (motion detection, door open/close, glass break, smoke, liquid detection, etc.)
  • Two-way Audio with built-in microphone and 3.5mm stereo audio output.
  • IR night vision supports up to 25 ft (7.5 m).
  • 1/4" CMOS sensor with 4x digital zoom.
  • Video streaming: H.264, MJPEG, and JPEG.
  • Frame rate: 30 fps at up to 720p
  • Lens: F2.0, 4.6 mm (0.18 in).
  • Pan and tilt:
    • Pan: 330°
    • Tilt: 115°
    • Auto-patrol preset positions: 10.
  • 10/100 Mbps Auto-MDIX Ethernet port for data and power connections.
    • Supports Power over Ethernet (PoE) – power supply not required.
    • Power consumption: 10.5W.
  • Micro SD memory card slot.
  • Requires Windows 8.1, 8, 7, Vista, XP or Windows Server 2003, 2008 for initial installation.
  • Operating temperature: 32 to 104°F (0 to 40°C).
  • Operating humidity: 0 to 90% non-condensing RH.
  • Dimensions WxDxH: 3.9x3.9x5.0 in (100x100x128 mm).
  • Compatible with ENVIROMUX-2D/5D/16D.
  • Mounting base and mounting hardware included.
  • Regulatory approvals: CE, FCC, RoHS.
Downloads & References

NTI Part # Price Quote Buy
ENVIROMUX-IPCAM-NPOE $296.00
